SZGH-SD2010(H) Absolutely type Servo Driver 220V AC 20A

AC Servo system, 50W to 11KW ac servo motor, which including incremental or absolute type encoder. AC servo driver which can support Modbus RS485, with 220VAC/380VAC! SZGH-SD2010（H）can work with absolutely type servo motor for 750W or 09 flange servo motor 1KW etc

Service Hotline

86 19928711953(Whatsapp & WeChat)

Video Center

Classification:

Servo Driver

Product Description

SZGH AC Servo system, 50W to 11KW ac servo motor, which including incremental or absolute type encoder. AC servo driver which can support Modbus RS485, with 220VAC/380VAC!

Main Feature:

1.Operate Steadily

2. High Precision

3. Big Power Range(50W-11KW)

4. Strong Overload Resistance

5. High Speed and Excellent Performance

Servo encoder type :

With Tamagawa encoder: Incremental(2500PPR)/Absolute Servo Motor(17bits/23bits)
PositionControl:Pulse+Direction,Modbus:RS485/EtherCAT/Canopen/PowerLink

Specification:

Driver Model	Control Mode			Rated Voltage (A)	Current （A)	Encoder Type	Matched Motor
Driver Model	Torque	Position	Velocity	Rated Voltage (A)	Current （A)	Encoder Type	Matched Motor
SZGH-SD2004	√	√	√	Single or 3phase 220VAC	9	Increment	50-600W
SZGH-SD2010	√	√	√	Single or 3phase 220VAC	12	Increment	750W-1.0KW
SZGH-SD2026	√	√	√	Single or 3phase 220VAC	18	Increment	750W-3.8KW
SZGH-SD2075	√	√	√	Single or 3phase 220VAC	35	Increment	2.3KW-7.5KW
SZGH-SD4038	√	√	√	3phase 380VAC	18	Increment	2.3KW-3.8KW
SZGH-SD4075	√	√	√	3phaes 380VAC	35	Increment	3.5KW-7.5KW
SZGH-SD2004(H)	√	√	√	Single or 3phase 220VAC	9	Absolute	50-600W
SZGH-SD2010(H)	√	√	√	Single or 3phase 220VAC	12	Absolute	750W-1.0KW
SZGH-SD2026(H)	√	√	√	Single or 3phase 220VAC	18	Absolute	750W-3.8KW
SZGH-SD2075(H)	√	√	√	Single or 3phase 220VAC	35	Absolute	2.3KW-7.5KW
SZGH-SD4038(H)	√	√	√	3phase 380VAC	18	Absolute	2.3KW-3.8KW
SZGH-SD4075(H)	√	√	√	3phaes 380VAC	35	Absolute	3.5KW-7.5KW
SZGH-SD2004(E)	√	√	√	Single or 3phase 220VAC	9	EtherCAT	50-600W
SZGH-SD2010(E)	√	√	√	Single or 3phase 220VAC	12	EtherCAT	750W-1.0KW
SZGH-SD2026(E)	√	√	√	Single or 3phase 220VAC	18	EtherCAT	750W-3.8KW
SZGH-SD2075(E)	√	√	√	Single or 3phase 220VAC	35	EtherCAT	2.3KW-7.5KW
SZGH-SD4038(E)	√	√	√	3phase 380VAC	18	EtherCAT	2.3KW-3.8KW
SZGH-SD4075(E)	√	√	√	3phaes 380VAC	35	EtherCAT	3.5KW-7.5KW
