GH1000MC 3-5 AXIS CNC milling controller with ATC+PLC
Overview: GH1000MC is 3-5 axis milling CNC controller with PLC,macro , ATC and encoder feedback function. And widely applied in CNC milling machinery; machining center; milling center; wood working machine; compatible with SZGH all of motor and driver.
Classification:
Product Description
▶ Features:
1)3-5 Axis Fully English Type CNC Milling controller
2) 800x600 8.4 inch real color LCD displayer
3) Electric Turret & Binary code turret,Max: 99 pcs tools
4) Support ATC , Macro function and PLC function
5) Max speed is 60m/min, feeding speed is 24m/min,0.1um control precision
6) Adapted servo spindle can realize spindle continous position,rigid tapping,rigid screw processing
7) High anti-jamming switch power(100V-240VAC 50Hz/60Hz -> 24VDC)
8) 64MB Memory , 56Mb user store room
9) With USB interface,it supports file operation in flash disk,system configuration and software upgrade
10) Position Control Mode:Pulse+Direction/AB Phase,Dual Analog voltage output of 0~10V
11) 32 bits ARM microprocessor+FPGA Technology.
12) Basic I/O: 36X36 , can be edited freely
13) cutter offset : C
